20000 lbs Electric Winch Waterproof 12V DC Wireless PWLX20000i12V

Sale!
20000 lbs Electric Winch Waterproof 12V DC Wireless PWLX20000i12V

20000 lbs Electric Winch Waterproof 12V DC Wireless PWLX20000i12V

Original price was: $1,322.50.Current price is: $921.57.

89 in stock

SKU: 1200-PWLX20000i12V Category:

Description

Product Description

Key Points:

MRC Rated Capacity 20000 lb
Voltage Battery Power 12 VDC
Wire Rope Included Steel °9/16 in x 85 ft | °14 mm x 26 m
Speed (f/m) / min 3.4~17 ft / 1~5 m
Control Included Wireless and Wired
Warranty 1 Year

Technical Specifications:

MRC Rated Capacity 20000 lb Transmission / Reducer Type 4-Stage Planetary
Number of Speeds 1 Speed Free Spooling Clutch Type Sliding Ring Gear
Voltage Battery Power 12 VDC Gear Ratio 544:1
Speed (f/m) / min 3.4~17 ft / 1~5 m Electric Control Box Reverse Solenoid Control Box
Control Voltage 12 V Accessories Control and Installation Hardware
Control Included Wireless and Wired IEC Motor Protection IP67
Motor Model DC Series Wound Motor Warranty 1 Year
Motor AMP 450 AMP Fairlead Included
Drum Brake In-Drum Automatic Brake Number of Layers 4
Wire Rope Included Steel °9/16 in x 85 ft | °14 mm x 26 m Drum DL Length 228 mm
1st Layer MRC Capacity 20000 lbs Drum BD Barrel Diameter 89 mm
FCC Cert ID 2ASYP-DW12K
