Hobbyist Grade Lift – Not intended for heavy commercial use
Baseplate, Open-Top Style Lift
2-Stage front arms/3-Stage rear arms
Automatic Arm Restraints
Single-Point Lock Release
Double Safety Lock System
Dual Hydraulic Chain-Drive Cylinders
Free 12 Piece Truck Adapter Set
Mounting Hardware Included
Shipping Weight: 1,300 lbs.
2 Years Manufacturer Warranty for Parts
5 Years Manufacturer Warranty for Lifting Structure
The Atlas® BP8000 is a baseplate two-post lift designed for low ceiling garages. The total column height of 108 inches or 9 feet allows this lift to be installed in almost any professional or home garage with a ceiling as low as 9 foot 3 inches. The BP8000 also has many of the popular features found on larger more expensive lifts, including a single-point lock release, Super-symmetric arms, and a twelve piece truck adapter set.
Optional Add-On (Not Included):
Baseplate Extension Kit
Atlas ATTD-BP8000 2-Post Lift Specifications:
Capacity 8,000 LB.
Overall Height 108″ (9’)
Overall Floor Width 132″ (11’)
Outside Column to Outside Column 124″ (10’ 4″)
Maximum Lift Height (Without Adapters) 76 3/4″
Maximum Lift Height (With Adapters) 87 3/4″
Minimum Arm Height 4″
Inside Column 109 1/8” (9’ 1 1/8”)
Drive Thru 99” (8’ 3”)
Column Size 7 1/4″ x 11″
Column Thickness of Steel 6mm
Base Of Lift 17 1/2″ x 17 3/4″
Motor/Electrical Requirement 220 volt single (1) phase (A 30 amp breaker is recommended)
