Greenlee CS-5000

Description

• Advanced bi-directional sensing technology allows user to hold receiver vertically or horizontally
• Equipped with superior sensitivity and functionality to provide accurate tracing and locating
• Front facing LED linear array display indicates relative signal strength
• Bright LEDs and audible signal provide dual notification to assist operator in challenging environments
• Traces concealed wiring, locates junction boxes, and finds breakers for live or open circuits
• Locates and identifies blown fuses
• Finds shorts and breaks in conductors
• Can be used on GFCI protected circuits
• Supports transmitter-to-receiver distances up to 4 miles for closed circuit tracing
• User-selectable automatic or manual gain capability for fast, convenient use
• Works on de-energized circuits with no need to have to have power on
• Suitable for works on live circuits without disrupting service
• Handle design creates comfortable, easy grasp to reduce hand fatigue
• Voltage Rating: 600V AC/DC
• Tracing Range Open Line Mode:
• Up to 10 ft. (3 m) with a metallic connection to ground
• 1 to 3 ft. (0.3 to 0.9 m) with a capacitive ground reference
• Tracing Range Live Line Mode: Up to 20. ft (6 m) from circuit
