PROMAX HD RANGER Eco

Description

• Triple split display: 3 functions in single screen
• Fast and accurate spectrum Analyzer
• StealthID: Identifying the tuning parameters
• Advanced satellite functions
• Powerful datalogger and installation menu
• USB PC connection
• Constellation diagram
• Dynamic echoes analysis
• Signal detection for DVB-T2/C2/S2, DVB-T/C/S; MPEG-2 MPEG-4
• General specifications:
  • Inputs and outputs:
    • RF input: F-type male, 75 Ohms
    • USB interface: Mini-USB. Mass storage host, Serial port emulation, USB CDC Communications Device Class
    • Video/Audio input: Jack multipole connector
  • Monitor display: 7 in. TFT, 16:9
  • Ext. unit power: Through RF input connector
    • Terrestrial supply: External, 5, 12 and 24 V
    • Satellite supply: External, 13 V, 15 V, 18 V
    • 22 kHz signal: Selectable in satellite band
    • DiSEqC generator: According to DiSEqC 1.2 standard
  • Dimensions: 290 (W.) x 185 (H.) x 65 (D.) mm
  • Battery operation time:> 2 hours in continuous mode
• Measurement Mode:
  • Displayed data: Numeric and Level bar
  • Tuning range: 5 to 1000 MHz (Terrestrial), 950 to 2150 MHz (Satellite)
  • DVB-T COFDM: 35 dBμV to 115 dBμV
    • Measures: Power, CBER, VBER, MER, C/N and Link margin
  • DVB-T2 Base and Lite COFDM: 35 dBμV to 115 dBμV
    • Measures: Power, CBER, C/N, LBER, MER, BCH ESR, LDP Iterations, Link Margin and Wrong packets
  • DVB-C QAM, J83 Annex C QAM: 45 dBμV to 115 dBμV
    • Measures: Power, BER, MER, C/N and Link margin
  • DVB-C2 COFDM: 45 dBμV to 115 dBμV
    • Measures: Power, CBER, MER, C/N, LBER, BCH ESR, LDP Iterations, Link Margin and Wrong packets
  • Analog TV PAL, SECAM and NTSC:
    • Standard supported: M, N, B, G, I, D, K and L
  • FM radio:
    • Measures: Level
  • DVB-S QPSK: 35 dBμV to 115 dBμV
    • Measures: Power, CBER, MER, C/N and Link Margin
  • DVB-S2 QPSK, 8PSK, 16APSK, 32APSK: 35 dBμV to 115 dBμV
    • Measures: Power, CBER, LBER, MER, C/N, BCH ESR, Wrong Packets and Link Margin
  • DSS QPSK: 35 dBμV to 115 dBμV
    • Measures: Power, CBER, VBER, MER, C/N, Link Margin and Noise Margin
• Spectrum Analyzer Mode:
  • Tuning range: 5 to 1000 MHz (Terrestrial), 950 to 2150 MHz (Satellite)
  • Reference level: 70 dBμV to 120 dBμV (Adjustable in steps of 5 dB)
  • Span: Full span / 500 MHz / 200 MHz / 100 MHz / 50 MHz / 20 MHz / 10 MHz
  • Measurement range: 20 to 120 dBμV
  • Measurement bandwidth: 100 kHz
• Video:
  • Codecs: MPEG-1, MPEG-2, MPEG-4 AVC H.264
  • Maximum image size: 1920 x 1080 x 60i; 1280 x 720 x 60p/50p
  • Audio CODECS: MPEG-1, MPEG-2, HE-AAC, Dolby Digital Plus
  • Tools: Constellation diagram, Dynamic echoes, Attenuation Test (2), Datalogger (3), PLS indicator, ISI filtering, Screen capture Key, Signal monitoring, Field strength, Task planner, H.265 detection
